Series 2400
Four-Flute Countersinks
Four flute countersink tool with specified countersink angle.
Diameter Range
0.2500" - 0.6250"
STANDARD Flute Length (Inch)
| Part Number |
Tool Size |
Dimensions (in) | Point Angle |
||
| Cutting Dia. (ØD) |
Flute Length (L2) |
Shank Dia. (Ød) |
|||
| 2400.2500.082 | 1/4" | 0.2500 | 0.500 | 1/8" | 82° |
| 2400.2500.090 | 1/4" | 0.2500 | 0.500 | 1/8" | 90° |
| 2400.2500.100 | 1/4" | 0.2500 | 0.500 | 1/8" | 100° |
| 2400.2500.120 | 1/4" | 0.2500 | 0.500 | 1/8" | 120° |
| 2400.2500.140 | 1/4" | 0.2500 | 0.500 | 1/8" | 140° |
| 2400.6250.090A1 | 5/8" | 0.6250 | 0.630 | 1/4" | 90° |
Part Numbers above include rings set at 0.800"
For Ringless Part Number, replace series "." with "-" (XXX-XXXX.XXXX)
Additional diameters and special ring colors available upon request
